Kingrail Parts is a manufacturer of coal mine cart wheels, for example: 600 gauge mine car wheel, 600 gauge mine cart wheel, material of rail cart wheel is 350 steel and cast iron, shaft thick have 50 mm, 55 mm, 60 mm, 75 mm diameter gauge, 600 round of 200, 240, 300, and 350 are all in stock, gauge 762, 900, 1435 to need to make to order.
Coal Mine Cart Wheels Specifications:
1. Material: cast steel or cast iron
2. Composition: two wheels, one axle, four bearings, other parts
3. Load capacity: 1-25 tons, each unit is OK
4. Wheel set specifications: 600mm, 762mm, 900mm, etc.
5. Wheel type: hollow wheel group and solid wheel group
6. Wheel diameter: 300mm, 350mm, 400mm, 450mm
7. Axle material: 45# steel or Q235
8. Number of bearings per wheel: two
9. Bearing material: LYC32212, tapered roller bearing, deep groove ball bearing
10. Weight: 70kg
Parameter of Cast Iron Ore Mining Cart Wheel Set:
|
Model |
Mine Car Weight kg |
Track mm |
Wheel Diameter |
Max Axle Distance of wheels |
Min distance of covers |
Axle diameter |
|
ZBL600/300 |
≤2400 |
600 |
300 |
808 |
510 |
60 |
|
ZBL762/300 |
762 |
970 |
672 |
|||
|
ZBL900/300 |
900 |
1108 |
810 |
|||
|
ZBL600/350 |
≤6700 |
600 |
350 |
850 |
490 |
80 |
|
ZBL762/350 |
762 |
1012 |
652 |
|||
|
ZBL900/350 |
900 |
1150 |
790 |
|||
|
ZBL600/400 |
≤9000 |
600 |
400 |
870 |
476 |
95 |
|
ZBL762/400 |
762 |
1032 |
638 |
|||
|
ZBL900/400 |
900 |
1170 |
776 |
