Kingrail Parts' drive wheels are specially designed for European-style cranes and are lightweight, high-performance and long-life.
We can customize crane drive wheels as per customer's specifications and requirements.
Specification:
Span: 7.5-25.5M
Capacity: 1--12.5 tons
Maximum wheel load: 13.5~90.94 knots
Tourist Railway: P24~P43
Trolley weight: 405~740 kg
Size:
| Name | Wheel width mm | Groove width mm |
| Ø125 driving wheel | 110 | ≤85 |
| Ø125 driven wheel | 110 | ≤85 |
| Ø140 driving wheel | 120 | ≤90 |
| Ø140 driven wheel | 120 | ≤90 |
| Ø160 driving wheel | 120 | ≤90 |
| Ø160 driven wheel | 120 | ≤90 |
| Ø200 driving wheel | 130 | ≤95 |
| Ø200 driven wheel | 130 | ≤95 |
| Ø250 driving wheel | 140 | ≤105 |
| Ø250 driven wheel | 140 | ≤105 |
| Ø315 driving wheel | 150 | ≤110 |
| Ø315 driven wheel | 150 | ≤110 |
Manufacturing process:
1. Material Cutting 2. Drilline 3. Rough Turning 4. Quenching Aad Tempering 5. Finish Turning 6. Oilling
